Request a QuoteBulk Class 3 Galvanized Horse Fence Factory
Bulk orders of Class 3 galvanized horse fence are produced for large‑scale equestrian facilities requiring uniform corrosion protection.
The zinc coating meets ASTM A123 Class 3 specifications, delivering a minimum average weight of 600 g/m².
This level of coating extends service life in outdoor paddocks, arenas, and pasture perimeters where exposure to moisture and soil is constant.
Continuous roll‑forming shapes low‑carbon steel into the desired panel profile before welding.
Immediate hot‑dip galvanizing follows, ensuring uniform coverage on all surfaces, including cut edges.
Standard panels are offered in heights ranging from 1.2 m to 2.0 m with lengths of 2.5 m or 3.0 m.
Wire diameter varies from 3.0 mm to 4.5 mm depending on load requirements.
The following table summarizes typical dimensional options and mechanical tolerances.
| Parameter | Typical Value | Unit | Notes |
|---|---|---|---|
| Height | 1.2 – 2.0 | m | Custom heights available on request |
| Length | 2.5 or 3.0 | m | Standard lengths; other lengths customizable |
| Wire Diameter | 3.0 – 4.5 | mm | Selected based on load and deflection criteria |
| Mesh Opening | 50 x 50 | mm | Square opening; alternative patterns possible |
| Tensile Strength (min) | 350 | MPa | Base steel before galvanizing |
| Coating Weight (avg) | 600 | g/m² | ASTM A123 Class 3 minimum |
Each batch undergoes coating weight verification using magnetic induction probes.
Tensile strength and elongation are tested per ASTM A370 to confirm mechanical integrity.
Customization Options
- Custom panel heights ranging from 1.0 m to 2.5 m
- Variable wire diameters and mesh spacing to suit specific load conditions
- Alternative top rail profiles such as rounded, square, or angled designs
- Pre‑drilled post holes or integrated brackets for rapid installation
- Special packaging configurations for containerized or break‑bulk shipments
Applications in Equine Facilities
Equine facilities demand fencing that resists chewing and kicking while maintaining a smooth surface to prevent injury.
The Class 3 zinc coating provides a durable barrier against rust, reducing maintenance cycles in high‑humidity regions.
Panel rigidity limits deflection under livestock pressure, preserving enclosure integrity over years.
Optional top rails with rounded profiles further minimize abrasion on horse coats.
Packaging and Shipping
Panels are bundled in groups of five and wrapped with UV‑stabilized polyethylene film.
Corner protectors and edge guards are added to prevent deformation during transit.
Each pallet is clearly labeled with lot number, coating class, and destination markings for easy inventory control.
Frequently Asked Questions
Yes, heights, lengths, wire diameters and mesh openings can be adjusted to meet project‑specific requirements.
Required details include desired panel size, quantity, coating class, any special features (e.g., top rail type, pre‑drilled holes) and delivery destination.
Coating weight is measured on each batch using non‑destructive magnetic induction probes, with results recorded and traceable to the lot number.
Lead times vary with order size and customization, but standard bulk shipments usually leave the factory within 3‑4 weeks after receipt of approved drawings and deposit.
