Best Price Flat Wrap Razor Wire Fencing Supplier
Flat wrap razor wire consists of high-tensile steel tape formed into a continuous helix with sharp barbs positioned at uniform intervals. The tape is cold‑rolled to achieve a uniform thickness of 0.5
Request a QuoteBest Price Flat Wrap Razor Wire Fencing Supplier
Flat wrap razor wire consists of high-tensile steel tape formed into a continuous helix with sharp barbs positioned at uniform intervals. The tape is cold‑rolled to achieve a uniform thickness of 0.5 mm ± 0.05 mm and a width of 22 mm ± 1 mm. This geometry provides a high barrier-to‑climb ratio while allowing rapid installation on posts or walls.
Product Overview
The product is supplied in coils of 50 m length, each coil weighing approximately 18 kg depending on steel grade. Coils are protected with a UV‑stabilized polyethylene sleeve to prevent corrosion during transit and storage. Ends are fitted with metal clips to maintain coil integrity until deployment.
Technical Specifications
| Parameter | Typical Value | Notes |
|---|---|---|
| Steel Grade | ASTM A1008 CS Type B | Cold‑rolled, high‑tensile |
| Tensile Strength | ≥ 550 MPa | Measured per ASTM A370 |
| Barb Height | 15 mm ± 1 mm | From tape centreline |
| Barb Spacing | 100 mm ± 5 mm | Center‑to‑center |
| Coil Diameter | 300 mm ± 10 mm | Inner core 50 mm |
Material Options
- Galvanized steel (Zinc coating 275 g/m²) for standard outdoor use.
- Stainless steel grade 304 for environments with high chloride exposure.
- PVC‑coated steel where additional abrasion resistance and colour coding are required.
Design Features
The flat profile reduces wind load compared with round barbed wire, making it suitable for high‑wind zones. The uniform barb distribution creates a consistent deterrent force, while the helix allows the wire to expand and contract with temperature changes without losing tension.
Installation typically uses U‑shaped brackets or specialized tensioning kits; the wire can be stapled, clipped, or welded to steel or concrete posts depending on structural requirements.
Applications
- Perimeter security for military bases, prisons, and detention centers where climb resistance is critical.
- Industrial facility boundaries to deter unauthorized vehicle and pedestrian access.
- Agricultural enclosures protecting high‑value crops from wildlife intrusion.
- Temporary site protection during construction projects, enabling rapid deployment and removal.
Quality Control
Each coil undergoes visual inspection for tape uniformity, barb alignment, and coating integrity. Dimensional checks are performed on a statistical sample using calibrated calipers to verify thickness, width, and barb spacing. Tensile testing is conducted on representative specimens to confirm compliance with the specified strength.
Coils are weighed and tagged with batch numbers; traceability records are maintained for at least two years to support any post‑delivery inquiries.
Customization
Length, barb height, and spacing can be adjusted to match specific threat assessments or regulatory standards. Coil weight and packaging (e.g., wooden pallets, corrugated boxes) are tailored to logistics constraints such as container size or handling equipment.
Surface treatments including hot‑dip galvanizing, electro‑galvanizing, or powder coating are available upon request to extend service life in corrosive environments.
Frequently Asked Questions
- Can dimensions be customized? Yes, tape width, barb height, and spacing are adjustable based on project requirements.
- What information is needed for a quotation? Required details include total length, steel grade, coating type, and any special packaging or labeling needs.
- How is quality inspected? Visual checks, dimensional sampling, and tensile testing per ASTM standards are standard procedures.
- What packaging options are available? Coils are typically wrapped in UV‑stabilized polyethylene and placed on pallets; custom crating or container‑fit packaging can be arranged.
- What is the typical lead time? Production usually begins within 7–10 business days after order confirmation, with shipping dependent on destination.
Contact for Quote
To obtain a detailed price estimate or discuss technical specifications, please provide your project parameters via the inquiry form.
