Request a QuoteWholesale Commercial Chain Link Fence – Price Per Foot
Chain link fencing is a cost‑effective barrier formed by interweaving steel wire into a uniform diamond pattern. Its open‑weave design provides visibility while delivering structural resistance to impact and wind loads.
Material & Construction
The fence core is low‑carbon steel wire, typically ASTM A123/ A123M galvanized with a minimum zinc coating of 270 g/m² for corrosion resistance. For environments requiring additional protection, a polyvinyl chloride (PVC) overcoat of 0.5 mm thickness can be applied, offering UV stability and color retention.
Wire diameters range from 9 ga (0.148 in) to 6 ga (0.192 in), directly influencing tensile strength and mesh rigidity. The diamond mesh is formed by helically winding the wire and interlocking each turn, creating a uniform opening size that determines climb resistance and visibility.
Key Specifications
| Parameter | Typical Value | Notes |
|---|---|---|
| Wire Gauge | 9 ga to 6 ga | Custom diameters available |
| Mesh Opening | 2 in (50 mm) or 2.25 in (57 mm) | Determines visibility and anti‑climb |
| Height Options | 4 ft, 5 ft, 6 ft, 8 ft, 10 ft | Custom heights on request |
| Coating | Hot‑dip galvanized (Zn 270 g/m²) or PVC overcoat | PVC colors: green, black, brown, white |
| Tensile Strength | ≈60,000 psi (steel core) | Dependent on wire gauge |
| Weight per Linear Foot | 0.8 lb/ft (9 ga, 2 in mesh) to 1.5 lb/ft (6 ga, PVC) | Varies with gauge, coating, height |
Performance Characteristics
The galvanized coating provides sacrificial protection, extending service life to 20 + years in mild climates and 10‑15 years in industrial atmospheres. PVC overcoat adds a barrier layer that prevents direct contact between the steel and corrosive agents, further increasing lifespan in chemical exposure zones.
Wind load resistance is calculated using the open area ratio; a 2 in mesh offers approximately 70 % openness, resulting in lower lateral forces compared with solid panels. This property makes chain link suitable for perimeter security where wind uplift is a design consideration.
Impact resistance is governed by the wire tensile strength and mesh geometry; a 6 ga wire can absorb kinetic energy from vehicular impacts up to 5 mph without permanent deformation, making it appropriate for low‑speed traffic barriers.
Typical Applications
- Industrial facility perimeters where visibility for surveillance and airflow is required.
- Sports field boundaries, providing containment while allowing spectator sightlines.
- Highway right‑of‑way fencing for wildlife deterrence and debris control, benefiting from low wind load.
- Temporary construction site enclosures, offering rapid installation and re‑usability.
- Agricultural livestock pens, where corrosion resistance and low maintenance are critical.
Customization Options
- Wire gauge selection from 9 ga to 4 ga for increased load bearing.
- Mesh opening adjustments (1.5 in, 2 in, 2.25 in, 3 in) to meet specific climb‑resistance or visibility criteria.
- Height customization up to 12 ft with intermediate posts and tension wire configurations.
- Coating choices: hot‑dip galvanized, galvanized‑plus‑PVC, or powder‑coated finishes in standard RAL colors.
- Accessory integration: barbed wire arms, privacy slats, or anti‑climb brackets can be factory‑installed.
Quality Assurance
Each production lot undergoes dimensional verification of wire diameter, mesh opening, and coating thickness using calibrated micrometers and magnetic coating thickness gauges. Tensile strength samples are pulled to failure in accordance with ASTM A370 to confirm minimum values.
Visual inspection checks for uniform zinc adhesion, absence of bare spots, and consistent PVC coverage. Any deviation beyond ±10 % of the specified coating weight triggers re‑processing.
Finished rolls are labeled with heat‑number, gauge, coating type, and length, enabling traceability back to the raw material batch for audits or warranty claims.
Pricing & Lead Time
Price is quoted per linear foot and varies with selected gauge, coating, and height. For example, a 9 ga galvanized fence at 6 ft height typically ranges from $2.80 to $3.30 per foot, while a 6 ga PVC‑coated version at 8 ft height falls between $5.20 and $6.00 per foot.
Standard lead time for stocked specifications is 7‑10 business days after receipt of purchase order. Custom gauges, heights, or coating colors extend lead time to 15‑20 business days, depending on raw material availability.
Volume discounts apply for orders exceeding 5,000 linear feet; freight terms are FOB factory with optional palletizing and stretch‑wrap for damage‑free transit.
Get a Quote
To receive a detailed quotation, please provide the required fence height, wire gauge, coating type, and total linear footage. Our engineering team will review the specifications and return a firm price with delivery schedule within one business day.
