Factory Direct Residential Black Chain Link Fence Manufacturer
Factory direct supply eliminates intermediaries, allowing tighter control over material traceability and production scheduling. This approach reduces lead time and provides clear documentation from
Request a QuoteFactory Direct Residential Black Chain Link Fence Manufacturer
Factory direct supply eliminates intermediaries, allowing tighter control over material traceability and production scheduling. This approach reduces lead time and provides clear documentation from raw wire to finished fence panel.
Materials and Construction
The fence core uses cold‑drawn steel wire with a nominal diameter of 2.0 mm, offering a tensile strength of approximately 550 MPa. Each wire is hot‑dip galvanized to a minimum coating weight of 275 g/m², providing corrosion resistance in outdoor environments. A black PVC overcoat of 0.5 mm thickness is applied, delivering UV‑stable color and additional barrier against moisture.
Technical Specifications
| Parameter | Typical Value | Notes |
|---|---|---|
| Wire diameter | 2.0 mm | Cold‑drawn high‑carbon steel |
| Galvanizing weight | ≥275 g/m² | Hot‑dip Zn coating |
| PVC overcoat thickness | 0.5 mm | UV‑stabilized black |
| Mesh opening | 50 mm × 50 mm | Standard square mesh |
| Fence height options | 1.2 m, 1.5 m, 1.8 m, 2.1 m, 2.4 m | Custom heights available on request |
| Roll length | 25 m per roll | Standard packaging |
Typical Applications
- Residential property demarcation where visual discretion is desired; the black finish blends with landscaping while providing a clear boundary.
- Pet containment systems; the 50 mm mesh prevents small animals from escaping while allowing airflow and visibility.
- Pool area enclosures; the corrosion‑resistant coating withstands splash and chlorinated environments.
- Garden and pathway barriers; the flexible roll format enables quick installation on uneven terrain.
Customization Options
- Wire diameter ranging from 1.8 mm to 2.5 mm to adjust tensile strength and flexibility.
- Alternative coating colors such as green, brown, or custom RAL matches upon request.
- Mesh opening sizes from 38 mm to 75 mm for specific security or visibility requirements.
- Height extensions beyond 2.4 m using spliced posts and tension wires.
- Pre‑stretched rolls or pre‑cut panels to reduce on‑site labor.
Quality Control Process
Each production lot undergoes inline tensile testing of wire samples to verify minimum 550 MPa strength. Galvanizing weight is measured using magnetic flux coating thickness gauges at three points per roll. PVC adhesion is checked via cross‑hatch tape test according to ASTM D3359, ensuring coating remains intact after bending. Final inspection includes visual examination for uniform color and mesh integrity before packaging.
Packaging and Shipping
Fence rolls are wrapped in UV‑stabilized polyethylene film, then placed on pallets with corner protectors to prevent edge damage. Each pallet is strapped with polyester bands and labeled with product code, length, and weight. For export, shipments are secured in ISO‑standard containers with desiccant packs to control humidity during transit.
Frequently Asked Questions
- Can dimensions be customized?
- Yes, wire diameter, mesh opening, height, and coating color can be adjusted to meet project specifications; provide detailed requirements for a quotation.
- What information is required before quotation?
- Required details include desired height, length, wire diameter, mesh size, coating type, and any special posts or accessories.
- How is quality inspected?
- Quality control includes tensile strength testing, galvanizing weight measurement, PVC adhesion testing, and final visual inspection as described above.
- What packaging methods are available?
- Standard packaging uses UV‑stabilized film on pallets; custom crating or container loading can be arranged upon request.
